Description
- Alle Geräte sind in moderner Inverter-Technologie aufgebaut
- Bestens geeignet für Montagearbeiten (auf der Leiter, auf dem Gerüst, …) und durch Schutzart IP 21 S generell auch für Arbeiten im Freien
- Genaue Einstellung der Schweißparameter über digitales Display
- Universell einsetzbar zum Verschweißen von allen gängigen Elektrodentypen
- Geeignet für den Einsatz am Generator z.B. in Betriebswerkstätten, Schulen, Metallbau, auf Baustellen oder für Landwirte
- HF-Hochfrequenz-Zündung zündet beim WIG-Schweißen, ohne das Werkstück zu berühren
- Durch die leise laufenden Lüfter wird die Wärme gut aus den Geräten abgeführt und damit eine hohe Einschaltdauer erreicht.
- Einstellbare Schweißkurve
- Zwei Jahre Schweißkraft-Garantie
- Gasschlauch 4m inkl. Schnellverbinder
- Brenner TIG 26 4m
- 3m Massekabel 16mm² mit Masseklemme
- 3m Schweißkabel 16mm² mit Elektrodenhalter
Features
| Anschlusskabellänge | 2,2 m |
|---|---|
| Anschlussspannung | 230 V +/- 10 % |
| Blechdicken | 1,0 - 8,0 mm |
| Breite/Tiefe (Produkt) ca. | 150 mm |
| Breite/Tiefe ca. | 150 mm |
| Brennerkühlung | Luft |
| Einschaltdauer bei max. Strom 40°C Elektrode | 30 % |
| Einschaltdauer bei max. Strom 40°C WIG | 30 % |
| Einstellbereich Elektrode | 5 - 200 A |
| Einstellbereich WIG | 5 - 200 A |
| EMV-Klasse | A |
| Erforderliche Generatorleistung | >10,8 kVA |
| Erläuterung EMV-Klasse | Diese Klasse A Schweißeinrichtung ist nicht für den Gebrauch |
| Gesamtleistung | 10,0/8,0 kVA |
| Gewicht (netto) ca. | 7,7 kg |
| Gewicht ca. | 7,8 kg |
| Höhe (Produkt) ca. | 280 mm |
| Höhe ca. | 280 mm |
| Länge (Produkt) ca. | 430 mm |
| Länge ca. | 430 mm |
| Leerlaufspannung |
|
| Leistungsaufnahme Elektrode | 6,2 kVA |
| Leistungsaufnahme WIG | 4,9 kVA |
| Leistungsfaktor | 0,75 cos phi |
| Negative Netzspannungstoleranz | 10 % |
| Netzfrequenz | 50/60 Hz |
| Norm | EN 60974-1 |
| Phase(n) | 1 Ph |
| Positive Netzspannungstoleranz | 10 % |
| Pulsfrequenz | 0,5 - 200 Hz |
| Schutzart | IP23 |
| Schweißbare Elektroden | 1,6 - 4,0 mm |
| Strom bei ED 100% 40°C Elektrode | 120 A |
| Strom bei ED 100% 40°C WIG | 120 A |
| Stromart | AC |
| Stromaufnahme Elektrode DC | 47,2 A |
| Stromaufnahme WIG DC | 32,9 A |
| Zündung | Hochfrequenz |
| DIN/ EN/ ISO/ Art | EN 60974-1 |
