Spiralbohrer HSS DIN338N 3,2mm 118G Typ N 4xD A5103.2 TiN Dormer

Dormer Pramet

Spiralbohrer HSS DIN338N 3,2mm 118G Typ N 4xD A5103.2 TiN Dormer

SKU	11140320
GTIN	7320760036518
MPN	7320760036518
Weight	0.01 kg
Width	0.01 m
Length	0.1 m
Height	0.01 m

11,65 €

Ø h8 3,2

Stahl kleiner 700 N/mm²: 47
Stahl kleiner 1000 N/mm²: 21
Stahl kleiner 1400 N/mm²: 11
A510, mit präzisem Spitzenanschliff und hoher Rundlauf- und Teilungs
Titan größer 850 N/mm²: 20

incl. VAT plus shipping

Delivery time: 1-3 Werktage

Stück

Description

Spiralbohrer mit zyl. Schaft, geschliffen

Ausführung: A510, mit präzisem Spitzenanschliff und hoher Rundlauf- und Teilungsgenauigkeit. Durch die spezielle Dormer ADX Geometrie erzielen Sie neben einer deutlich erhöhten Performance eine verbesserte Bohrungsqualität.

Hersteller: Dormer Pramet s.r.o., Am Weichselgarten 34, 91058 Erlangen, DE, +4991319330870, info.uk@dormerpramet.com

Features

Features
Ø h8	3,2 mm
Spirallänge	36 mm
Gesamtlänge	65 mm
Stahl kleiner 700 N/mm² f	0,1 mm/U
Stahl kleiner 700 N/mm²	47
Stahl kleiner 1000 N/mm²	21
Stahl kleiner 1400 N/mm²	11
INOX ferrit./martens.	35
INOX austenitisch	35
INOX duplex	20
Guss GG/GTS	42
Guss GGG	32
Titan größer 850 N/mm²	20
Alu kleiner 8% Si	40
Alu größer 8% Si	50
Kupfer Cu-Leg.	50
Graphit GFK/CFK/Duropl.	28
Beschichtung	TiN

Manufacturer

Dormer Pramet,ZNL d.Sandvik Tool. DE GmbH
Am Weichselgargen 34
91058 Erlangen
09131/933740
www.pramet.de
pramet.info.de@pramet.com
