Description
Features
| Ausführung | Pistolengriff |
|---|---|
| Neu im Jahr | 2026 |
| Breite metrisch | 56 mm |
| Luftverbrauch, bei Last | 0.14 m³/min |
| Luftverbrauch, Leerlauf | 0.14 m³/min |
| Anzahl der Öltropfen [min] | 5 Tropfen |
| Nettogewicht | 3.05 kg |
| Luftqualität [DIN ISO] | 8573-1 |
| Luftqualität [Partikel/Wasser/Öl] | 2/2/4 |
| Umgebungstemperatur im Betrieb | -10 / + 40 |
| Mind. Ø Zuluftschlauch Innen | 10 mm |
| Frequenz Hübe | 5500 Hub/min |
| Ölviskosität | 22-32 cSt |
| max. Betriebsdruck | 6.3 bar |
| Unsicherheit K - Geräusch | 3 db(A) |
| Unsicherheit K - Schwingung | 0.3 m/s² |
| Schwingungsemissionswerte ah/ah, SG |
|
| Abluftaustritt | vorne |
| Höhe | 165 mm |
| Länge metrisch | 290 mm |
Downloads
Manufacturer
August Rüggeberg GmbH & Co. KG
PFERD-Werkzeuge
Hauptstraße 13
51709 Marienheide
Deutschland
Telefon: + 49 2264 9-0
Telefax: + 49 2264 9-400
e-mail: info@pferd.com
Safety regulations
General safety instructions
• All electrical connections must be made by an authorized electrician
• Machines may only be operated with functioning safety devices
• Only allow trained personnel to operate the machine
• Maintenance and repair work may only be carried out by trained personnel
• Never work under the influence of illnesses that impair concentration, medication, drugs or alcohol
• Machines must always be disconnected from the power supply before maintenance or repair work
• Wear tight-fitting clothing and remove all objects that could cause you to get caught in machines.
• Use original spare parts and accessories
• Keep body parts away from moving parts of the machines.
• In the event of a malfunction or unusual behavior, operation must be stopped immediately until the cause has been clarified and the error has been rectified.
• Avoid overloading machines. Always work within the permitted performance range (technical data)
• Always ensure that no one is in the danger areas of the machines.
• Before using the machines, make sure that the safety devices are working properly
• Read the operating instructions and familiarize yourself with the safety devices.
• Keep the work area clean and tidy to minimize sources of danger
• Do not make any changes to machines
• Wear hearing protection to protect your hearing
• Wear appropriate safety gloves when handling chemicals or sharp objects
• Wear appropriate safety shoes to protect your feet
• Wear appropriate safety clothing
• Always observe and follow all safety instructions that are attached to the product or included with the product.

- Passender Nadelentroster für das Nadelset mit 28 Nadeln.
