Description
Ausführung: Aus gehärtetem Stahl, mit federnder Tastfläche.
Anwendung: Zur Lagebestimmung von Werkstückflächen oder Werkzeuglängen in Z-Richtung auf Dreh- oder Fräsmaschinen. Das Gerät wird auf das Werkstück aufgesetzt. Mit der Maschinenspindel wird dann das Schneidwerkzeug, z. B. Fräser, auf die Tastfläche gefahren, bis der Zeiger der Messuhr auf null steht. Der Abstand vom Schneidwerkzeug zum Werkstück beträgt jetzt genau 50 mm, dadurch werden die Schneiden beim Messen nicht beschädigt.
Lieferumfang: Nulleinsteller mit Messuhr.
Hersteller: Tschorn GmbH, Dieselstraße, 73660 Urbach, DE, +4971816069860, info@tschorn-gmbh.de
Features
| Tastteller-Ø | 20 mm |
|---|---|
| Gehäuse-Ø | 39 mm |
| Variante | Nulleinsteller ohne Magnetfuss TSCHORN |
Manufacturer
Tschorn GmbH Mess- und Spannmittel
Dieselstraße 8
73660 Urbach
07181/6069860
www.tschorn-gmbh.de
info@tschorn-gmbh.de
