Description
- Sehr schwere und robuste Schweißkonstruktion
- Dynamischer Antrieb der Biegewange mittels zwei frequenzgeregelter Motoren mit Getrieben
- Oberwangenklemmung über Trapezgewinde
- Hochwertige Lenze-Motoren
- Durchgehende Scharfbiegeschiene
- Werkzeuge zum Biegen von Edelstahl geeignet
- Biegewinkeleinstellung über Touchscreen NC-Steuerung
- Blechdickeneinstellung manuell an der Biegewange
- Manuelle Bombiereinrichtung der Biegewange
- Bedienung über Doppelfußpedal mit Notausfunktion
- Rein motorische Maschine ohne Hydraulik
- SH-Modelle mit segmentierten, hohen Geißfußwerkzeugen
- DUO-Modelle mit durchgehender Scharfbiegeschiene und hohen, segmentierten Geißfußwerkzeugen
Features
| Abgabeleistung Biegen | 2 x 4,0 kW |
|---|---|
| Abgabeleistung Wange | 4,0 kW |
| Arbeitsbreite max. | 2020 mm |
| Biegeleistung 400 N/mm² | 8,0 mm |
| Biegeleistung 700 N/mm² | 6 mm |
| Biegeleistung Aluminium | 9,6 mm |
| Biegeleistung max. Aluminium | 9,6 mm |
| Biegeleistung max. Stahl 400 N/qmm | 8,0 mm |
| Biegeleistung max. VA-Stahl | 6 mm |
| Breite ca. | 1500 mm |
| Breite/Tiefe (Produkt) ca. | 1500 mm |
| Durchlass zwischen Ober- und Unterwange max. | 350 mm |
| Erläuterung Biegeleistung 700 N/mm² | Standardwerkzeuge zum Biegen von Edelstahl geeignet |
| Gewicht (netto) ca. | 5380 kg |
| Gewicht ca. | 5380 kg |
| Höhe (Produkt) ca. | 1750 mm |
| Höhe ca. | 1750 mm |
| Länge (Produkt) ca. | 3480 mm |
| Länge ca. | 3480 mm |
Zubehör
Sonstiges
obligatorisch
Ausgewählt
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26
96103 Hallstadt
0951/96555-0
www.stuermer-maschinen.de
info@stuermer-maschinen.de
Safety regulations
General safety instructions
• All electrical connections must be made by an authorized electrician
• Machines may only be operated with functioning safety devices
• Only allow trained personnel to operate the machine
• Maintenance and repair work may only be carried out by trained personnel
• Never work under the influence of illnesses that impair concentration, medication, drugs or alcohol
• Machines must always be disconnected from the power supply before maintenance or repair work
• Wear tight-fitting clothing and remove all objects that could cause you to get caught in machines.
• Use original spare parts and accessories
• Keep body parts away from moving parts of the machines.
• In the event of a malfunction or unusual behavior, operation must be stopped immediately until the cause has been clarified and the error has been rectified.
• Avoid overloading machines. Always work within the permitted performance range (technical data)
• Always ensure that no one is in the danger areas of the machines.
• Before using the machines, make sure that the safety devices are working properly
• Read the operating instructions and familiarize yourself with the safety devices.
• Keep the work area clean and tidy to minimize sources of danger
• Do not make any changes to machines
• Wear hearing protection to protect your hearing
• Wear appropriate safety gloves when handling chemicals or sharp objects
• Wear appropriate safety shoes to protect your feet
• Wear appropriate safety clothing
• Always observe and follow all safety instructions that are attached to the product or included with the product.
