Description
- Zum Herstellen von allen rundgeformten Teilen wie Rohren, Zylindern usw.
- Walzenantrieb über Handkurbel oder motorisch bei E-Modellen
- Schwere und stabile Gusseisenkonstruktion
- Asymmetrisches 3-Walzensystem zum bequemen Vorbiegen
- Die obere Walze ist ausstellbar, dadurch einfache Entnahme des fertigen Werkstücks
- Ausschwenkbare Oberwalze
- Leicht verstellbare Ober- und Unterwalze
- Möglichkeit zum konischen Biegen
- Mit Sicherheitseinrichtungen
- Serienmäßige Drahteinlegerille auf Unter- und Hinterwalze
- Durch die Fußbedienung bleiben beide Hände frei für die Materialzuführung
- Angetriebene Ober- und Unterwalze
- Drahteinlegerille auf Unter- und Hinterwalze
Features
| Abmessung (L x B x H) | 1650 x 1020 x 1110 mm |
|---|---|
| Anschlussspannung | 400 V |
| Arbeitsbreite max. | 1270 mm |
| Biegebreite max. | 1270 mm |
| Biegedurchmesser min. | 110 mm |
| Biegeleistung max. - Aluminium | 1,8 mm |
| Biegeleistung max. - Material-Zugfestigkeit 400N/qmm | 1,5 mm |
| Biegeleistung max. - VA-Stahl | 1,1 mm |
| Biegeleistung max. Aluminium | 1.8 mm |
| Biegeleistung max. Stahl 400 N/mm² | 1.5 mm |
| Biegeleistung max. VA-Stahl | 1.1 mm |
| Breite/Tiefe (Produkt) ca. | 1020 mm |
| Durchmesser Obere Walze | 75 mm |
| Durchmesser obere Walzen | 75 mm |
| Gesamt Stromaufnahme | 2,5 A |
| Gewicht (netto) ca. | 318 kg |
| Gewicht (Netto) ca. | 318 kg |
| Gewicht ca. | 318 kg |
| Höhe (Produkt) ca. | 1110 mm |
| Konischbiegeleistung max. - Aluminium | 0,9 mm |
| Konischbiegeleistung max. - Material-Zugfestigkeit 400N/qmm | 0,8 mm |
| Konischbiegeleistung max. - VA-Stahl | 0,6 mm |
| Konischbiegeleistung max. Aluminium | 0.9 mm |
| Konischbiegeleistung max. Stahl 400 N/mm² | 0.8 mm |
| Konischbiegeleistung max. VA-Stahl | 0.6 mm |
| Länge (Produkt) ca. | 1650 mm |
| Leistung Antriebsmotor | 0,75 kW |
| Motorleistung | 0,75 kW |
| Netzfrequenz | 50 Hz |
| Netzspannung | 400 V / AC |
| Schutzart Antriebsmotor | IP 44 |
| Walzengeschwindigkeit | 4 m/min |
Ersatzteile
obligatorisch
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26
96103 Hallstadt
0951/96555-0
www.stuermer-maschinen.de
info@stuermer-maschinen.de
Safety regulations
General safety instructions
• All electrical connections must be made by an authorized electrician
• Machines may only be operated with functioning safety devices
• Only allow trained personnel to operate the machine
• Maintenance and repair work may only be carried out by trained personnel
• Never work under the influence of illnesses that impair concentration, medication, drugs or alcohol
• Machines must always be disconnected from the power supply before maintenance or repair work
• Wear tight-fitting clothing and remove all objects that could cause you to get caught in machines.
• Use original spare parts and accessories
• Keep body parts away from moving parts of the machines.
• In the event of a malfunction or unusual behavior, operation must be stopped immediately until the cause has been clarified and the error has been rectified.
• Avoid overloading machines. Always work within the permitted performance range (technical data)
• Always ensure that no one is in the danger areas of the machines.
• Before using the machines, make sure that the safety devices are working properly
• Read the operating instructions and familiarize yourself with the safety devices.
• Keep the work area clean and tidy to minimize sources of danger
• Do not make any changes to machines
• Wear hearing protection to protect your hearing
• Wear appropriate safety gloves when handling chemicals or sharp objects
• Wear appropriate safety shoes to protect your feet
• Wear appropriate safety clothing
• Always observe and follow all safety instructions that are attached to the product or included with the product.
