Description
- Stufenlos einstellbare Doppelgehrung und Neigung nach links
- Grundplatte und Drehteller aus Aluminium-Druckguss, zugleich kompakt, robust und leicht transportierbar
- Laserprojektion auf dem Werkstück zur genauen Kontrolle der Schnittposition
- Seitlich ausziehbare Auflagehilfen für längere Werkstücke
- Zweifach einstellbare Kapptiefenbegrenzung
- Zugfunktion für erweiterten Schnittbereich
- Serienmäßig mit Niederhalter zur sicheren Werkstückarretierung
- Absaugstutzen für Staubfangbeutel oder den Anschluss einer externen Absaugung
- Niederhalter
- Staubfangbeutel
- Sägeblatt
Features
| Abmessung | 650 x 450 x 430 mm |
|---|---|
| Anschlagschienen | starr |
| Anschlussspannung | 230 V |
| Breite/Tiefe (Produkt) ca. | 450 mm |
| Drehzahl | 4500 min-1 |
| Elektrischer Anschluß |
|
| Gewicht (netto) ca. | 10,5 kg |
| Gewicht ca. | 10,5 kg |
| Höhe (Produkt) ca. | 430 mm |
| Länge (Produkt) ca. | 650 mm |
| Leistung Antriebsmotor | 1,5 kW |
| Max. Gehrung links | 45 ° |
| Max. Gehrung rechts | 45 ° |
| Max. Kopfneigung links | 45 ° |
| Motorleistung | 1,5 kW |
| Neigung 0 / Gehrung 45° links | 220 x 35 mm |
| Neigung 0° / Gehrung 0° | 220 x 70 mm |
| Neigung 45° / Gehrung 0° links | 155 x 70 mm |
| Neigung 45° / Gehrung 0° rechts | 155 x 70 mm |
| Neigung 45° / Gehrung 45° links | 155 x 35 mm |
| Neigung 45° / Gehrung 45° rechts | 155 x 35 mm |
| Nennweite außen Absaugstutzen | 32,5 mm |
| Netzfrequenz | 50 Hz |
| Sägeblattabmessungen | 210 mm |
| Sägeblattdrehzahl | 4500 min?¹ |
| Sägeblattdurchmesser | 210 mm |
| Schalldruckpegel | 93,6 dB(A) |
| Schallleistungspegel | 106,6 dB(A) |
| Schnittkapazität bei 0° Neigung / 0° Gehrung | 220 x 70 mm |
| Schnittkapazität bei 0° Neigung / -45° Gehrung | 220 x 35 mm |
| Schnittkapazität bei -45° Neigung / 0° Gehrung | 155 x 70 mm |
| Schnittkapazität bei -45° Neigung / -45° Gehrung | 155 x 35 mm |
| Stromart | AC |
| Vibrationsemission | 4,58 m/s² |
Ersatzteile
Zubehör
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26
96103 Hallstadt
0951/96555-0
www.stuermer-maschinen.de
info@stuermer-maschinen.de
Safety regulations
General safety instructions
• All electrical connections must be made by an authorized electrician
• Machines may only be operated with functioning safety devices
• Only allow trained personnel to operate the machine
• Maintenance and repair work may only be carried out by trained personnel
• Never work under the influence of illnesses that impair concentration, medication, drugs or alcohol
• Machines must always be disconnected from the power supply before maintenance or repair work
• Wear tight-fitting clothing and remove all objects that could cause you to get caught in machines.
• Use original spare parts and accessories
• Keep body parts away from moving parts of the machines.
• In the event of a malfunction or unusual behavior, operation must be stopped immediately until the cause has been clarified and the error has been rectified.
• Avoid overloading machines. Always work within the permitted performance range (technical data)
• Always ensure that no one is in the danger areas of the machines.
• Before using the machines, make sure that the safety devices are working properly
• Read the operating instructions and familiarize yourself with the safety devices.
• Keep the work area clean and tidy to minimize sources of danger
• Do not make any changes to machines
• Wear hearing protection to protect your hearing
• Wear appropriate safety gloves when handling chemicals or sharp objects
• Wear appropriate safety shoes to protect your feet
• Wear appropriate safety clothing
• Always observe and follow all safety instructions that are attached to the product or included with the product.
