Description
- Sehr kompakt durch Aluminiumprofile, hochwirksames Adsorptionsmittel und integrierte Staubfilter
- Vorgespanntes Adsorptionsmittel: dadurch auch horizontaler Betrieb möglich und Trockner unempfindlich gegen Vibrationen
- Vorgespanntes Adsorptionsmittel: dadurch auch horizontaler Betrieb möglich und Trockner unempfindlich gegen Vibrationen
- Service- und wartungsfreundlich wegen Serviceanzeige, Trockenmittelkartuschen, Selbstdiagnose, Funktionsanzeige, PC-Schnittstelle
- Energiesparend durch standardmäßige Memory-Funktion (Kompressorgleichlaufsteuerung); Optional weitere Programmiermöglichkeit zur Leistungsanpassung
Adsorptionsmittel in Wechselkartuschen
- Staubfilterelemente in Wechselkartuschen integriert
- Adsorptionsmittel in Kartuschen mit Feder vorgespannt
- Adsorptionsmittel: Molekularsieb
Display mit Anzeigen für:
- Spannungsversorgung
- Ventilfunktion links / rechts
- Service vorbereiten (11.500 und 23.500 Betriebsstunden)
- Service nötig (12.000 und 24.000 Betriebsstunden)
- Über LED codierte Fehlermeldungen für Funktion der Magnetventile und der Elektronik
- Kondensatableiter in Funktion
Elektronische Steuerung:
- Breitband-Netzteil für 100 - 240 VAC; 50 - 60 Hz, 12 - 24 VDC
- Prozessor mit CPU, Selbstdiagnose
- Service-Rücksteller
- PC-Schnittstelle zur Programmanpassung und Fehlerdiagnose, optionale PC-Software
- Energiemanagement; Energieeinsparung durch Kompressorgleichlauf
- Potentialfreier Störmeldekontakt
Filtration
- CLEARPOINT-Feinstfilter am Trocknereintritt
- Staubfilter in Wechselkartuschen integriert
Kondensatableiter
- Integrierter Kondensatableiter (zeitgesteuertes Magnetventil) oder alternativ: BEKOMAT 20 FM am Eintrittsfilter
Features
| Abmessung (L x B x H) | 281 x 184 x 1065 mm |
|---|---|
| Breite/Tiefe (Produkt) ca. | 184 mm |
| Drucktaupunkt tpd | -40 °C |
| Gewicht (netto) ca. | 47 kg |
| Gewicht (Netto) ca. | 47 kg |
| Gewicht ca. | 47 kg |
| Höchstdruck | 16 bar |
| Höhe (Produkt) ca. | 1065 mm |
| Länge (Produkt) ca. | 281 mm |
| Luftanschluss | G 3/8 " |
| Luftanschluß |
|
| Luftvolumenstrom m³/h | 85 m³/h |
Zubehör
