Description
- Präzise und sorgfältige Verarbeitung
- Komplett aus gedämpfter, massiver Rotbuche
- Alle wichtigen Kanten sind gerundet
- Oberflächen umweltfreundlich geölt
- Serienmäßig mit Werkzeuglade
- Die zwei Zylinderstäbe der Spannzangen sind präzise und stabil in einem Gussteil geführt
- Mit leichtgängiger Trapezgewindespindel
Ausstattung:
- Besonders schwere Ausführung des Tisches und Untergestells für festen Stand
- Französische Vorderzange mit Doppelspindel mit verdeckter Übersetzung mittels Zahnrädern und Kette
- Deutscher Hinterzange mit doppelter Linearführung
- Schwere und stabile Zangenführungen
- Schwalbenschwanz-Verzinkung in Hinterzange und Beiladerücken
- zwei Rundbankhaken kurz
- zwei Rundbankhaken lang
- Schublade
- Beilade
Features
| Arbeitshöhe | 870 mm |
|---|---|
| Breite Hinterzange | 140 mm |
| Breite Vorderzange | 100 mm |
| Breite/Tiefe (Produkt) ca. | 855 mm |
| Breite/Tiefe Arbeitsfläche ohne Zangen | 615 mm |
| Gewicht (netto) ca. |
|
| Hinterzange Breite | 140 mm |
| Hinterzange Länge | 460 mm |
| Hinterzange Spannweite | 215 mm |
| Höhe (Produkt) ca. | 870 mm |
| Länge (Produkt) ca. | 2165 mm |
| Länge Arbeitsfläche ohne Zangen | 1910 mm |
| Länge Hinterzange | 460 mm |
| Länge Vorderzange | 700 mm |
| Max. Tragkraft | 750 kg |
| Plattenstärke | 80 mm |
| Spannweite Hinterzange | 215 mm |
| Spannweite Hinterzange bis Mitte Rundhaken | 300 mm |
| Spannweite Vorderzange | 250 mm |
| Spannweite Vorderzange bis Mitte Rundhaken | 305 mm |
| Tragkraft max. | 750 kg |
| Vorderzange Breite | 100 mm |
| Vorderzange Länge | 700 mm |
| Vorderzange Spannweite | 250 mm |
