Description
- Modernste Inverter- Technologie
- WIG Schweißen mit LIFT Zündung
- Geeignet für den Einsatz am Generator z.B. in Betriebswerkstätten, Schulen, Metallbau, auf Baustellen oder für Landwirte
- Hot Start: Durch einstellbare kurzzeitige Erhöhung des Schweißstromes zündet der Lichtbogen sicher und ist sofort stabil
- Anti Stick: Beim versehentlichen Festkleben der Elektrode wird der Schweißstrom automatisch reduziert und somit ein Ausglühen der Elektrode verhindert
- Arc-Force-Regelung: Durch die interne Überwachung von Schweißstrom und Schweißspannung werden Kurzschlüsse schnell und sicher aufgelöst. Durch die einstellbare Anhebung des Stroms wird der Lichtbogen stabilisiert und die Elektrode kann problemlos verarbeitet werden.
- VRD (Volt Reduction Device): Spannungsabsenkung im Leerlauf
- Schweißkabel 3 m 50 mm² mit Elektrodenhalter 500 A
- Massekabel 3 m 50 mm² mit Masseklemme 500 A
Features
| Anschlussspannung | 400 V |
|---|---|
| Breite/Tiefe (Produkt) ca. | 240 mm |
| Breite/Tiefe ca. | 240 mm |
| Einschaltdauer bei max. Strom 40°C Elektrode | 60 % |
| Einschaltdauer bei max. Strom 40°C WIG DC | 60 % |
| Einstellbereich Elektrode | 20 - 400 A |
| Einstellbereich WIG | 20 – 400 A |
| Einstellbereich WIG DC | 20 - 400 A |
| EMV-Klasse | A |
| Erforderliche Generatorleistung | > 22,4 kVA |
| Erläuterung EMV-Klasse | Diese Klasse A Schweißeinrichtung ist nicht für den Gebrauch |
| Gesamtleistung Elektrode | 22,4 kVA |
| Gesamtleistung WIG | 17,3 kVA |
| Gewicht (netto) ca. |
|
| Höhe (Produkt) ca. | 440 mm |
| Höhe ca. | 440 mm |
| Kennzeichnung | CE |
| Länge (Produkt) ca. | 560 mm |
| Länge ca. | 560 mm |
| Leistungsaufnahme Elektrode | 16,4 kVA |
| Leistungsaufnahme WIG DC | 12,4 kVA |
| Netzfrequenz | 50/60 Hz |
| Norm | EN 60974-1 |
| Phase(n) | 3 Ph |
| Schweißbare Elektroden |
|
| Strom bei ED 100% 40°C Elektrode | 310 A |
| Strom bei ED 100% 40°C WIG DC | 310 A |
| Stromart | AC |
| Stromaufnahme | 32.3/25,1 A |
| Stromaufnahme Elektrode | 32.3 A |
| Stromaufnahme WIG | 25.1 A |
| DIN/ EN/ ISO/ Art | EN 60974-1 |
