Description
- Beim Einschalten der Holzbearbeitungsmaschine läuft die Absauganlage mit einer Verzögerung von 2-3 Sekunden automatisch an
- Zusätzliches Einschalten der Absauganlage entfällt
- Beim Abschalten der Arbeitsmaschine läuft die Absauganlage noch ca. 3-4 Sekunden nach
- Der Reststaub wird nach dem Abschalten der Arbeitsmaschine laut Gefahrenstoffverordnung abgesaugt
- Schutz vor Netzüberlastung beim Einschalten
- Beim Betrieb der Anlaufautomatik mit einem Absauggerät der Typen ASA 1901, 1903 und 2803 muss ab Werk zusätzlich der Schalterdeckel ASA mit Schalter zum Dauerbetrieb für Einschaltautomatik gekauft werden (zur Selbstmontage)
Features
| AbsaugStromanschluß | 1 x 400 V / 16A 1 x 230 V |
|---|---|
| AC-3 | 230V / 13,5A / 3 kW; 400V / |
| Anschlussleistung max. | 4 kW |
| Anschlussspannung | 400 V |
| Breite/Tiefe (Produkt) ca. | 123 mm |
| Gewicht (Netto) ca. | 1,25 kg |
| Höhe (Produkt) ca. | 153 mm |
| Länge (Produkt) ca. | 245 mm |
| MaschinenStromanschluß | 1 x 400 V / 16A 1 x 230 V |
| max. Anschlußleistung m. 4 mtr. Netzkabel | 4,0 kW / 400 V / 16 A / Stecker |
| Netzanschluß 50-60Hz | 400 V / 16 A |
| Netzfrequenz | 50 / 60 Hz |
| Schutzart | IP44 |
| Steckdosen verzögert Schaltvermögen | AC-1 |
| Stecker für Netzanschluss | 400V / 16A |
| Stromanschluss Absauggerät | 1 x 400V 16A / 1 x 230V |
| Stromanschluss Maschine | 1 x 400V 16A / 1 x 230V |
Sonstiges
Hauptartikel
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26
96103 Hallstadt
0951/96555-0
www.stuermer-maschinen.de
info@stuermer-maschinen.de
